EXPLOSION PROOF (G SERIES)

$0.00

Green Ignite's Explosion Proof G Series

  • CLASS I, DIVISION I

Consumption:

Green Ignite's Explosion Proof G Series

  • CLASS I, DIVISION I

PART NUMBERS

GI-EPG-C100-G4 | 20W | 2,800LM | 100-277V | 5000K

GI-EPG-C150-G4 | 30W | 4,200LM | 100-277V | 5000K

GI-EPG-C175-G4 | 40W | 5,600LM | 100-277V | 5000K

CLASSIFICATIONS

Marking UL844 (North American):
Class I, Division 1, Groups C, D
Class I, Division 2, Groups A, B, C, D
Marking UL844 (North American)
Class II, Division 1, Groups E, F, G
Class II, Division 2, Groups F, G
Class III

Marine Marking:
UL 1598, UL1598A ABS IP66
Impact Resistance (Shock): |K10

Other Rating:
IP66
IK10

    • Rated for high temperatures, humidity, dust and vapor locations

    • Various installation options for particular applications

    • Heavy duty & high impact resistant

    • 0-10V Dimmable

    • Tempered glass for high heat resistance

    • Beam Angle: 120 Degrees

    • Ambient Temperature (F): -40- 149 Degrees

    • Efficacy: 140lm/W

    • 10KvA Surge protection

  • GI-ACC-EPCW
    Ceiling / Wall mount

  • GI-ACC-EPPG
    Protective guard

    GI-ACC-EPG
    Globe

    GI-ACC-EPHS
    Heat sink

  • GI-ACC-EPPM
    Pendant mount

    GI-ACC-EPWE
    Wall elbow

    GI-ACC-EPSMA
    Surface mounting arm

    GI-CAA-EP25S
    25 Degree pole support

    GI-ACC-EP90WJB
    90 Degree wall support & junction box

    GI-ACC-EP25WS
    25 Degree wall support

    GI-ACC-EP90S
    90 Degree pole support

  • GI-ACC-EPR
    Reflector

    GI-ACC-EPEX
    Extension

    GI-ACC-EPSSP
    Straight swing pipe

    GI-ACC-EPPB
    Bended pipe

    GI-ACC-EPJB
    Junction box

    GI-ACC-EPPS
    Photocell sensor

    GI-ACC-EPED08
    8W Emergency back-up kit

  • G SERIES EXPLOSION PROOF SPEC SHEET

  • Mounting Bracket: Stainless steel

    Bolts: Stainless steel

    Diffuser: Tempered glass

    Housing: Copper free aluminum
