EXPLOSION PROOF (R SERIES)

$0.00

Green Ignite’s explosion proof R series fixtures

  • CLASS I, DIVISION II

Consumption:

Green Ignite’s explosion proof R series fixtures

  • CLASS I, DIVISION II

PART NUMBERS

GI-EPR-C175-C1D2 | 30W | 4,200LM | 100-277V | 5000K
TYPE 1 - STAINLESS STEEL

GI-EPR-C175HO-C1D2 | 40W | 5,600LM | 100-277V | 5000K
TYPE 1 - STAINLESS STEEL

GI-EPR-C250-C1D2 | 50W | 6,500LM | 100-277V | 5000K
TYPE 1 - STAINLESS STEEL

GI-EPR-C250HO-C1D2 | 60W | 7,800LM | 100-277V | 5000K
TYPE 1 - STAINLESS STEEL

GI-EPR2-C175-C1D2 | 30W | 4,200LM | 100-277V | 5000K
TYPE 2 - FIBER REINFORCED PLASTIC

GI-EPR2-C250-C1D2 | 50W | 6,500LM | 100-277V | 5000K
TYPE 2 - FIBER REINFORCED PLASTIC

CLASSIFICATIONS

Marking UL844(North American)
Class I, Division 2, Groups A, B, C, D
Class II, Division 1, Groups E, F, G
Class II, Division 2, Groups F, G Class III

Marking ATEX
II2G Ex db eb mb |IC T5/T6 Gb
II2 D Ex tb IIIC T95°C/T85°C Db IP66
Marking IECEX
Ex db eb mb IIC T5/T6 Gb
Ex tb IIIC T95°C/T85°C Db

Marking Marine
UL 1598
UL 844

Other Rating
IP66
IK10

    • Rated for high temperatures, humidity, dust and vapor locations

    • 2 Cable entry points on each side

    • Heavy duty & high impact resistant

    • 0-10V Dimmable

    • Smooth housing allows for easy cleaning / maintenance

    • Efficacy: 140lm/W

    • CRI: 80

    • Ambient temperature (F): -40 - 140 Degrees

    • 10KvA Surge protection

  • GI-ACC-EPRMW
    Steel rope mounting wire

    GI-ACC-EPCMK
    Ceiling mounting kit

  • GI-ACC-EPFLF-PM
    Pole mount

  • GI-ACC-EPJB
    Junction box

    GI-ACC-EPPS
    Photocell sensor

  • R SERIES SPEC SHEET

    HAZ LOC EFFICIENITE SELECT ™ [EPR SERIES]

  • Gasket: Silicone rubber

    Hardware: Aluminum alloy

    Housing: Stainless steel or fiber reinforced plastics
